YEAR: 1995
-Model: 4STR36
-Capacity: 36″ x 0.200″ x 30,000psi yeild strength
36″ x 0.150″ x 60,000psi
36″ x 0.110″ x 90,000psi
-Entry Peeler and Holddown Roll
-Entry Edge Guides, Manual adjustment
-Entry Pinch Rolls: 3.25″ Dia. x 35″ Face (2 Sets)
-7 Work Rolls, 3 over 4
3.25″ Dia. x 37.5″ Face Rolls
-Exit Pinch Rolls: 3.25″ Dia. x 38″ Face
-Loop Control: Sona-Trol
-5 HP Baldor Motor, 1750 RPM, 575 Volt, 3 PH, 60 HZ.
-Gear Reducer w/20:1 Ratio
-Line Direction: Left to Right
-Passline: 63″
-Operating Manual and Drawings included.
-Overall Size: 123″ L (with Holddown Roll) x 70″ W x 78″ High
-Approx. Weight: 4,930#
